- Synchronous data rates: 19.2, 32, 56, 64 and 128 kbps; Asynchronous data rates: 0–38.4 kbps
- Full-duplex operation over a single twisted pair (2-wires)
- Point-to-point distances up to 5 miles (all data rates) on 24 AWG twisted pair
- Internal, external or receive recovered clocking options (1082/I)
- LED indicators for TM, ER, NS, DSL (1082 C & D), 10Base-T (1082/I), and Status (1082/I); DSL, G.703, LOS, NS, ER, TM (1082/F)
- V.35 and X.21 Interfaces (1082 C & D); Ethernet Interface (1082/I); Co-directional 64 kbps G.703 (1082/F)
- Multi-Rate Symmetric DSL
- Interoperable with Popular Models 1092, 1092/A, 1092ARC, and 3092
- SNMP Manageable with 1092ARC and 1001MC as 1001MC SNMP Agent Rack Card, or 3092
The Patton Model 1082 Series is a high speed, AC powered short range modem that is able to operate synchronously or asynchronously—full duplex—over a single twisted pair. Supporting data rates to128 kbps (synchronous) or 38.4 kbps (asynchronous), the Model 1082 is capable of point-to-point distances up to 5 miles using 24 AWG wire.
The Model 1082 Series supports internal, external or receive loopback clocking in synchronous mode. Data rates and asynchronous data format may be configured locally using DIP switches.
Model 1082/C provides a V.35 interface on an M/34 female connector. Model 1082/D provides an X.21 interface on a DB-15 female connector. Line connection is made by an RJ-45 jack. Standard versions of Model 1082 Series are powered by a 100–240VAC (Universal) supply. The DC power supply option supports any DC input between 36–72VDC.
|
