| Number of Connections: |
16 |
| Power Supplies: |
Dual Redundant (Fixed) AC |
| Ethernet Ports: |
Two 10/100Base-T |
| WAN Ports: |
4 |
| Modem Modulations: |
V.92, V.90, K56Flex™, V.34 Annex 12, V.34, V.32bis, V.32, V.23, V.22, V.22bis, V.21, Bell 212A, Bell 202, Bell 103, EIA-PN-2330, V.8, V.8bis, Sync/Async receiver/transmitter for V.14, V.42/V.42bis error correction & compression |
| PSTN Signaling: |
E1 Primary Rate interface (Q.931), E1 MFR2 (R2), T1 Primary Rate Interface, T1 Robbed bit with Loop/Ground Start or E&M Wink, E&M Immed, Taiwan R1 and Drop & Insert |
| Management Services: |
HTTP, SNMP, TELNET Dial-in and Ethernet or RS-232 console port, SYSLOG client, Remote software upgrade via FTP, User configurable login prompts and banners |
| Authentication: |
RADIUS, PAP/CHAP, Username/Password, and Static Users Database (111 Entries) |
| Software Upgrades: |
Achieved through Flash upgrades via FTP. Software available at upgrades.patton.com |
| Warranty: |
1-Year Standard Warranty. Upgrade available to a 5-year Enhanced Waranty (includes Advance Replacements) |
| Protocol Services: |
TCP/IP suite with extensive protocol statistics—ICMP/TFTP/FTP/RLOGIN/TELNET • Ethernet ARP, Proxy ARP and RARP protocols • Point-to-Point Protocol (PPP) • SLIP protocol • Van Jacobson TCP header compression PPP address and protocol compression • RADIUS authentication and accounting, with support for primary and secondary servers • RIP, RIPv2 and OSPF dynamic route distribution*—user configurable static routes • MultiLink PPP • Multi-chassis MultiLink • Layer 3 and Layer 4 IP Filtering • NFAS • DNIS |
| Dial-out Services: |
ial-out with support for multi-link PPP • Single-line call-back • Remote authentication using PAP and CHAP and session time |
|
